Frame
Crafty Stealth Air Full Carbon, Updated Zero Suspension System, 150mm Travel, Forward Geometry, Internal Removable Battery, Boost 12x148mm Rear Axle, UDH, Tapered Head Tube, One-Piece Monoblock Upper Link, HHG Internal Cable Routing, MAX Capacity Sealed Bearings, Oversized 15mm Axles, Exclusive Plastic Motor Covers
Sizes
S: 380mm
M: 410mm
ML: 435mm
L: 460mm
XL: 490mm
Rear Shock
Öhlins TTX22M.2, 185x55mm, High-Speed Compression Lever with Climb Mode, Low-Speed Compression, Rebound, Spring Preload, Trunnion Top Mount, 30x8mm Bottom Bushings
Shock Settings
C20 Compression, R40 Rebound
Spring Rates
S: 411 lbs
M: 457 lbs
ML: 502 lbs
L: 548 lbs
XL: 605 lbs
Fork
Öhlins RXF 38 M.3 29, 160mm, TTX18 Twin Tube Cartridge, Tapered Steerer Tube, Boost 15x110mm Axle, 44mm Offset
Headset
Acros Custom ZS56/ZS56, 1-1/8"–1.5" Head Tube, Internal Cable Routing, Sealing Plugs Without Blocklock
Stem
Onoff S9 30mm, 0°, Full CNC, 31.8mm Clamp
Handlebar
Onoff S9 1.0 Carbon, 800mm Width, 8° Backsweep, 5° Upsweep, 31.8mm Clamp
S–ML: 25mm Rise
L–XL: 38mm Rise
Grips
Onoff Desert Pro, CNC Lock-On, 135mm
L–XL: Thicker Size
Seatpost
RockShox Reverb Stealth AXS, 31.6mm
S: 398.2 x 125mm
M: 448.2 x 150mm
ML: 498.2 x 175mm
L: 548.2 x 200mm
XL: 548.2 x 200mm
Saddle
Fizik Vento Argo 00 Carbon, 150mm
Front Brake
Trickstuff Maxima, 7075-T6 CNC Alloy 4-Piston Caliper, 203mm Rotor
Rear Brake
Trickstuff Maxima, 7075-T6 CNC Alloy 4-Piston Caliper, 203mm Rotor
Brake Levers
Trickstuff Maxima, 7075-T6 CNC Alloy, Lever Pivot Bearings, Tool-Free Reach Adjust, Kevlar Hose
Wheelset
DT Swiss HXC1200 Carbon Spline 29
30mm Internal Width
Hookless
Tubeless Ready
28 Spokes
Spokes
DT CompLite® Hybrid T-Head
Front Hub
DT 180, Boost 15x110mm, IS 6-Bolt
Rear Hub
DT 180, Boost 12x148mm, Ratchet EXP OS 42 System, IS 6-Bolt, XD Freehub
Front Tire
Maxxis Minion DHF 29 x 2.5, 3C MaxxGrip Compound, EXO+ Protection, Tubeless Ready
Rear Tire
Maxxis Minion DHR II 29 x 2.5, 3C MaxxTerra Compound, EXO+ Protection, Tubeless Ready
Crankset
ethirteen Helix Race Carbon ESpec Plus, 160mm
Chainring
SRAM XX Eagle 34T T-Type, Direct Mount, Steel, CL55
Chain
SRAM XX Eagle T-Type, 12-Speed, PowerLock
Rear Derailleur
SRAM XX Eagle AXS T-Type, 12-Speed
Shifter
SRAM Eagle AXS Pod Rocker, 12-Speed
Cassette
SRAM XS-1295 T-Type, 10–52T, 12-Speed
Display
Bosch Kiox 400 / Bosch Mini Remote
Motor
Bosch Performance Line CX-R Smart System (25 km/h) (BDU386Y)
Battery
Bosch PowerTube 800Wh
Additional Info
Bikes ship free in the continental US, arrive fully assembled, come set up tubeless, and include complimentary suspension setup based on rider weight.
